Key product highlights will be added soon.
Detailed specifications will be added soon.
| Specification | Details |
| Product Brand | Audirect |
| Product Model | Atom Mini |
| Product Type | Portable USB Digital-to-Analog Converter (DAC) & Headphone Amplifier |
| Audio DAC Chipset | ESS ES9280AC PRO |
| Crystal Oscillator | 1× High-Performance Femtosecond Oscillator |
| Digital Audio Resolution | PCM / DXD up to 32-bit / 768kHz |
| DSD Support Specification | Native DSD up to DSD512 |
| Frequency Response | 20Hz - 40kHz (0.032dB) |
| Total Harmonic Distortion (THD+N) | 0.0004% |
| Signal-to-Noise Ratio (SNR) | ≥117dB |
| Dynamic Range (DNR) | 117dB |
| Output Power (16Ω Load) | 584mVrms (103dB) |
| Output Power (32Ω Load) | 1.40Vrms (106.7dB) / Approx. 62mW |
| Output Power (600Ω Load) | 2.07Vrms (107dB) |
| Input Interface Options | USB Type-C or Lightning (Hardware variant dependent) |
| Output Interface Port | 3.5mm Single-Ended (SE) Headphone Jack |
| Format Status Indicator | Multi-color LED (Red: 44.1/48kHz, Blue: 88-384kHz, Green: 705-768kHz, Yellow: DoP, White: DSD) |
| Power Architecture | Battery-free Bus-powered (Plug and Play low consumption design) |
| Body Construction Material | Premium Aluminum Alloy Housing with Braided Outer Cable Layer |
| Net Structural Weight | 8.0 grams (0.28 oz) |
