| Specification | Detail |
| Product Type | Portable USB-C DAC & Headphone Amplifier |
| DAC Chip | Cirrus Logic CS43198 |
| Operational Amplifier (Op-Amp) | SG Micro SGM8262 |
| PCM Decoding | Up to 32-bit / 384 kHz |
| DSD Decoding | Native DSD256 (1-bit / 11.2 MHz) |
| Output Power | ~195 mW @ 32 Ω (THD+N < 1%) |
| Output Impedance | ~0.65 Ω |
| Signal-to-Noise Ratio (SNR) | ~125 dB (32 Ω, A-weighted) |
| Dynamic Range (DNR) | ~120 dB (32 Ω) |
| Total Harmonic Distortion (THD+N) | ~0.0003% (32 Ω) |
| Noise Floor | ~1.3 μV (32 Ω, A-weighted) |
| Crosstalk Suppression | ~ -70 dB (32 Ω) |
| Input Interface | USB Type-C (UAC 1.0 / UAC 2.0 protocol switching) |
| Output Interface | 3.5 mm Single-Ended Audio Jack |
| Hardware Controls & Features | 3-level hardware EQ switching, inline mic & call playback support |
| Cable Construction | 8-strand mixed weave silver-plated copper wire (448 cores) |
| Chassis Material | 5-axis CNC-machined aluminum alloy with curved tempered glass |
| Total Length | 110 ± 10 mm |
